Re-Verber-Ray QTD2 Series

The Re-Verber-Ray QTD2 Series is a powerful dual-stage, quad tube, multi-burner, low intensity heater. The innovative QTD2 is unique and offers an innovative heating solution for a range of both indoor and outdoor applications. When you choose the QTD2, you'll enjoy a bevy of exceptional benefits that lead to increased comfort levels and minimized energy costs.

At Applied Technologies of New York, we are the authorized manufacturer's representative for the entire Detroit Radiant Products lineup. And our experienced factory-trained sales engineers will carefully listen to your application and facility's needs to lead you to the best and most ideal Re-Verber-Ray low intensity heater. In the meantime, let's take a closer look at the dynamic Detroit Radiant Products Re-Verber-Ray QTD2 Series heater.

Get to Know the Detroit Radiant Products Re-Verber-Ray QTD2

The Re-Verber-Ray QTD2 is offered in several different models spanning from 60,000 BTU/h up to 80,000 BTU/h. It boasts a cutting-edge design that incorporates the modular benefits of high-intensity infrared with the versatility of low-intensity infrared.

It's engineered with a distinctive construction that features a multi-exchanger, multi-burner, multi-reflector platform enhanced for an even and broad heat output pattern. The optimized two-stage feature of the QTD2 Series delivers increased comfort levels while minimizing your overall energy costs.

With a patent pending, the two-stage QTD2 Series heater is perfect across a range of both indoor and outdoor applications. The Detroit Radiant Products Re-Verber-Ray QTD2 offers:

  • An expansive input range spanning from 40,000 up to 80,000 BTU/h
  • The QTD2 measures a total of 112 inches in length
  • Operates on both Propane (10” W.C.) or Natural Gas (3.5” W.C).
  • Features Coated Aluminum Steel Radiante Emitter Tubes
  • Features a Coated Enameled Steel Burner Control Box

When you choose the Detroit Radiant Products Re-Verber-Ray QTD2 Series, you'll enjoy a reliable, low-intensity heater with a robust warranty:

  • 1 Year Limited Warranty on Components
  • 3 Year Limited Warranty on Tubes
  • 5 Year Limited Warranty on the Burner

Available Re-Verber-Ray QTD2 Models

The QTD2 is offered in four different models that alternate between Natural Gas and Propane with different outputs and mounting heights

Model

Gas

High Fire

BTU/h

Low Fire

BTU/h'

Length

Weight

LBS.

Mounting Heights

QTD2-60N

Natural

60,000

40,000

112"

140

8' to 12'

QTD2-60P

Propane

60,000

40,000

112"

140

8' to 12'

QTD2-80N

Natural

80,000

50,000

112"

140

10' to 14'

QTD2-80P

Propane

80,000

50,000

112"

140

10' to 14'

Key Features of the Detroit Radiant Products Re-Verber-Ray QTD2 Series

With an aesthetically pleasing and compact design, the QTD2 Series is engineered to perform under pressure without being obtrusive. Some of the key features and attributes of Detroit Radiant Products Re-Verber-Ray QTD2, include:

  • The QTD2 low intensity heater is simple to install and requires very little assembly.
  • This innovative low intensity heater boasts several construction features like highly-emissive heat exchangers, dual spark ignition, operational indicator lights, polished reflectors, and more.
  • It combines the versatility of being infrared heater with cutting-edge enhancements to deliver proven fuel savings.
  • The QTD2 is packaged and engineered for easy transportation.

Why Choose the QTD2 for Infrared Heating?

The QTD2 is designed to heat objects (walls, people, and surfaces) instead of air — like traditional heating systems. Due to this fact, infrared systems deliver an immediate warming sensation — similar to the way you'll feel when the sun shines from behind the clouds. The operation of the QTD2 offers a full suite of benefits, including:

  • You'll have the ability to direct heat wherever it's needed the most.
  • Without relying on currents of air to circulate and transfer heat, the QTD2 boasts improved indoor air quality.
  • Infrared heating systems can deliver anywhere from 20% up to 50% in fuel savings in comparison to traditional systems.
  • Because the QTD2 is clean burning, it boasts low harmful emissions.
  • You and other building occupants will enjoy improved comfort thanks to the system heating the floor and people — not the air.
  • It features an innovative modular design that allows you to establish individual zone controls.

Contact ATI of New York for the Re-Verber-Ray QTD2

If you're looking for a versatile, powerful, and efficient infrared heater for indoor or outdoor applications, the Re-Verber-Ray QTD2 by Detroit Radiant Products may be your most ideal solution. And the experts at ATI of New York can conduct an in depth needs analysis to match your facility to the perfect QTD2 model.

Contact Applied Technologies of New York today to learn more about the QTD2 Series.
