Re-Verber-Ray HLV Series

If you need a specialty heater for vast commercial or larger industrial applications, the Detroit Radiant Products Re-Verber-Ray HLV Series is up for the task. This innovative two-stage, multiple burner system is the premier solution for applications where reduced penetrations are needed while covering a greater area with heat. The HLV Series boasts potential operating benefits that aren’t easily obtainable with other types of infrared tube heaters.

At ATI of New York, we offer the entire lineup of Detroit Radiant Products, and we’ll match your unique facility needs to the best Re-Verber-Ray HLV Series model. Continue reading to learn more about the dynamically powerful and versatile Re-Verber-Ray HLV Series line of infrared heaters.

The Detroit Radiant Products Re-Verber-Ray HLV Series

The HLV Series is a multiple-burner engineered vacuum infrared heating system that is extremely versatile — offering 1 to 6 different burner design solutions. You’ll enjoy a tandem burner design for independent combustion air for each individual burner.

The HLV Series boasts an expansive operating range, spanning from 40,000 BTU/h up to an impressive 750,000 BTU/h. Considering the immense heating capacity of the HLV series, it’s typically used for specialty commercial and larger industrial applications, such as:

  • Distribution Centers
  • Large Warehouses
  • Aircraft Hangers
  • Fire Station Apparatus Bays
  • Vehicle Storage Facilities
  • And more

The HLV features a patented two-stage operation that works to maximize comfort levels in the facility. The two-stage operation also works to increase efficiency by reducing equipment cycling to deliver exceptional energy savings. In addition, the Re-Verber-Ray HLV Series offers:

  • Self-diagnostic circuitry and operation indicator lights
  • Spark-resistant, cast aluminum, pre-wired, vacuum pump that has thermal overload.
  • The heavy-duty damper that achieves a 20% reduction in output when the system is operating in low fire.

Due to the high-quality materials and expert craftsmanship, Detroit Radiant Products stands behind the Re-Verber-Ray HLV Series with an excellent warranty:

  • 3-Year Limited Warranty on Components
  • 5-Year Limited Warranty on the Tubes
  • 10-Year Limited Warranty on the Burner
  • 1-Year Limited Warranty on the Pump

The Innovative Multiple-Burner Engineered Vacuum Heating System

The HLV Series features an engineered vacuum system that delivers consistent, low intensity heat just like other types of tubular heaters. The operational objective of the vacuum system is to circulate hot gases from the burner to the pump.

This movement works to heat the emitter pipe, which then can heat the building through infrared energy — just as any other type of tubular heater would. However, the HLV’s engineered vacuum system or negative pressure system offers additional benefits that are not easily obtainable with traditional tube heaters, such as:

  • Added flexibility to accommodate extended tube lengths for heating larger facilities or structures;
  • Accommodation for different elevation changes; and
  • Allows you to tie multiple burners onto a single vacuum pump, which results in reduced vent penetrations.

The HLV’s engineered vacuum system is unique in the way it operates and provides expanded operational boundaries. It’s engineered to employ both condensing technology and two-stage technology to deliver enhanced performance, optimized operating efficiencies, and exceptional fuel efficiencies.

Key System Components of an Engineered Vacuum System

Burner Control Assembly

The innovative tandem designed burners in the HLV Series offer a range spanning from 40,000 up to 200,000 BTU/h. Because every burner draws its own fresh air for combustion, they do not need combustion air filters.

Vacuum Pump

Heavy-duty cast aluminum, spark resistant, pre-wired aluminum pumps (.5 HP, .75 HP, or 1 HP) allow for several high BTU burners per system.

Controls

It features available state-of-the-art, pre-programmed building management control panels that can be used as an overall building management system or a stand-alone system.

Emitter Pipe

16 gauge, 4-inch O.D. titanium stabilized and aluminized steel tubes — enhanced by a emissive black coating — work to provide exceptional protection and longevity. The tube design is swaged and interlocking to create a tube-on-tube overlap.

This helps ensure a tight seal, excellent structural integrity, and provides installation simplicity. The condensing systems are designed with 304 stainless steel, which prevents corrosion and delivers years of reliability.

Reflectors

Highly-polished, multi-faceted reflectors optimize the amount of infrared energy directed to the areas where heat is needed the most.

Why Choose an Infrared Heating System?

Instead of choosing a traditional system that works to heat the air, infrared systems heat people, the floors, walls, and other surfaces. Because of this efficiency, infrared systems deliver an instant warming sensation — similar to the feeling you have when the sun begins to peek from behind the clouds. This unique operation drives a range of infrared heating system benefits, including:

  • Improved indoor air quality due to not relying on currents of air to transfer and circulate heat.
  • You’ll enjoy anywhere from 20% up to 50% in fuel savings compared to traditional heating system.
  • With outstanding flexibility, you can direct the heat where it is needed the most.
  • As a clean burning solution, infrared heaters put off low harmful emissions.
  • The modular design of infrared heaters allows you to create individual zone controls, which means those in the facility will enjoy increased comfort.
  • Infrared heating systems heat people and the floor — not the ceiling. And when heat energy is stored within ambient objects, it improves comfort.

Contact ATI of New York for the Re-Verber-Ray HLV Heating System

If you’re looking for a powerful, versatile, and efficient heating solution for a large commercial or industrial space, the Re-Verber-Ray HLV Series by Detroit Radiant Products may be your best solution. Fortunately, the experts at ATI of New York can help you decide. We are the authorized manufacturer's representative for Detroit Radiant Products and will match you facility's needs to the best heating solution.

Contact ATI of New York today.
