The Small But Mighty Power Flame Type X4 Burner

The Small But Mighty Power Flame Type X4 Burner

The Power Flame Type X4 burner represents an innovative generation of gas power burners engineered to fire both propane and natural gas against a positive furnace pressure. The Power Flame X4’s name is the result of it being a compact and versatile four-inch diameter burner.

The X4 family of compact gas burners boasts the capability of firing against a positive back pressure of more than 1.5 inches W.C. Because of this flexibility, X4 burners can adapt to a seemingly endless range of heating and process applications.

The Power Flame Type X4 burners deliver a new level of performance and are more robust and efficient than any other 4” diameter burners available on the market. Continue reading to learn more about the small, but mighty Power Flame X4 burner proudly offered by Applied Technologies of New York.

The Powerful Simplicity of the Power Flame Type X4

Although the X4 is high-tech, it only requires the connection of a 115V electrical supply, minor gas train piping, operating controls, and connection to gas service. This efficient simplicity makes the Power Flame X4 the ideal solution for a wide range of facilities and applications. This self-contained unit is comprised of:

  • Blower assembly
  • Control panel
  • Firing head
  • arrow-right
    Flame safeguard
  • arrow-right
    Ignition system
  • arrow-right
    Combination gas valve

Small & Powerful Power Flame Type X4 Burner

The Type X4 burners deliver an entirely new level of performance. Although it’s only four inches in diameter, it lacks nothing in performance. The unique diffuser firing head/gas manifold allows air and fuel to quickly mix, which creates a compact and stable flame that can power through most applications.

The innovative design of the gas pilot assembly ensures the main flame is reliably ignited. Each Power Flame Type X4 burner is thoroughly tested and CUL/UL listed, which means this family of burners can easily meet the most demanding application requirements. The Type X4 family of burners can be equipped with:

  • Direct spark ignition
  • 6-inch, 9-inch, or 12-inch blast tubes
  • Optional CSD-1 compliance
  • arrow-right
    On-Off or Modulating operating modes

Totally Enclosed Control Panel

The Type X4 burner features a totally enclosed control panel. This means the most important controls will remain be protected, but operators can easily gain access to these operating components.

Adjustable Mounting Flange

The adjustable mounting flange allows facilities the optimum amount of flexibility. Operators can quickly and easily adjust it to varying bolt patterns and firing head insertion depths to meet your needs.

Multi-Louvered Combustion Air Damper Assembly with Setting Graduations

Each Type X4 burner boasts a multi-louvered combustion air damper assembly with setting graduations. This means you can quickly and easily gain more accurate control of fuel-air ratios.

Four-Inch Circular Furnace Opening

The engineers of the Power Flame Type X4 burner created this modern marvel with maintenance simplicity in mind. Instead of needing to recertify your burner after manipulating the combustion chamber, the Type X4 requires no additional cutting or manipulation of the front plate of the combustion chamber.

Pre-piped & Prewired Gas Train

The Type X4 burner features a pre-piped and prewired gas train, which includes a combination dual shut-off gas valve/pressure regulator.

The Power Flame Type X4 Standard Features

The Power Flame Type X4 burner offers a diverse range of outputs, ranging from 400,000 up to 725,000 BTU/HR. You can choose from the following Power Flame X4 models:

  • X4-400
  • X4-700
  • X4M-400
  • arrow-right
    X4M-700
  • arrow-right
    X4M-400 HTD
  • arrow-right
    X4M-700 HTD

Regardless of the model you choose, each Type X4 includes a generous amount of standard equipment, such as:

  • 24-Volt control transformer
  • 3450 RPM motor, easy-to-access control panel, and an adjustable damper
  • Combination pressure regulator/ dual shut-off gas valve
  • arrow-right
    Air safety switch
  • arrow-right
    24-volt flame safeguard with intermittent pilot, flame rod, and prepurge.

The Power Flame Type X4 Optional Features

In addition to a generous offering of standard equipment, you can customize your Type X4 burner to meet the exact needs of your facility or application with a wide range of optional features. For example the CSD-1 compliance with 120-volt control is optional on the following models:

  • X4-700
  • X4M-700
  • X4M-700 HTD

Contact ATI of New York for the Power Flame Type X4 Burner

Power Flame has been creating the most cutting-edge products through continuous research for more than 50 years. The remarkable Power Flame Type X4 Burner encompasses their decades of experience and continuous drive for purposeful innovation.

Applied Technologies of New York is proud to be the authorized manufacturer’s representative for Power Flame. This means we’re able to offer the entire cutting-edge lineup of Power Flame’s products, including:

It also means our sales engineers have the experience to understand your unique facility or application needs. Then we can help you understand all of your options and guide you toward the best solution.

Contact ATI of New York today to learn more about the Power Flame Type X4 Burner or any other Power Flame product.
