A Complete Guide to the Power Flame Type FDM Burner

A Complete Guide to the Power Flame Type FDM Burner

If you're looking for an innovative and reliable gas burner, the Power Flame FDM will meet your needs and exceed your expectations. This gas burner boasts an exceptional operational range spanning from 30,000 up to 5,000,000 BTU. The Power Flame Type FDM is a remarkable HVAC and process burner engineered to fire process heating appliances as well as air handling systems that need indirect or direct heating of the air stream.

Every Power Flame Incorporated burner is infused with more than a half of a century of exceptional experience and cutting-edge solutions to deliver optimum efficiency and performance. Power Flame burners are versatile enough to cover a myriad of applications across virtually all industries.

ATI of New York is proud to be the authorized manufacturer's representative for Power Flame Inc. In addition to their entire line of cutting edge boiler room equipment, we're proud to offer the Power Flame Type FDM burner. Let's take a closer look at the Power Flame Type FDM.

The Power Flame Type FDM Burner

The Power Flame Type FDM Burner is manufactured to meet your process heating needs. It can also meet the needs of air handling systems that require indirect or direct heating of the air stream. The direct-fired, fixed air model FD can fire at either at 90 degrees or in line with the process air flow — achieving turndowns of 40:1 or greater. However, the indirect fired, modulating air model FDM burner can achieve on-ration control over a 20:1 turndown.

The Power Flame Type FDM is suitable for an expansive list of air heating and process heating applications — thanks to its high combustion efficiencies, reliable direct spark ignition, and low maintenance. As a part of an integrated combustion package, the Type FDM is available with prepiped and prewired gas trains. It can be configured to meet your specific requirements as well as your any local or national codes.

The Type FDM Is Engineered for High-Turndown Operations

The Power Flame Type FDM is engineered for high turndown operation firing into heat exchangers for air handling applications or directly into process streams of air, such as ovens and other types of lower temperature industrial applications. The Type FDM burner is fitted with moveable air dampers to the inlet of the blower assembly that facilitates on-ratio control over an impressive 20:1 turndown range. The Type FDM burner is ideally suited for indirect fired units requiring high turndowns. It can also be applied on direct fired applications where on-ratio control is required.

Power Flame Type FDM Key Standard Features

The Power Flame Type FDM comes equipped with a generous selection of high-quality standard features, including:

  • 3450 RPM Fan Motor
  • Combustion Air Switch Connectors
  • Modulating Combustion Air Damper
  • Flame Rod
  • Ignition Electrode
  • Modulating Butterfly Gas Valve
  • Ignition Transformer
  • Modulating Motor
  • Combustion Flow Air Switch
  • Combustion Control System

Power Flame Type FDM Optional Features

You can further customize your Power Flame Type FDM burner to meet the specific needs of your application with the following optional features:

  • UV Scanner
  • Prepiped and Prewired Gas Trains
  • Alternate Mode of Operation
  • Custom Control Panels
  • Wall Penetration Protection Sleeve

Power Flame Type FDM Burner Ratings and Specs

Depending on your facility's requirements, you can choose from a total of six different Power Flame Type FDM burners — with max natural gas capacity ranging from as low as 30,000 up to 5,000,000 BTU

Burner Model

Max Nat. Gas Capacity (BTU)

Min Nat. Gas Capacity (BTU)

FDM 75

750,000

37,500

FDM 150

1,500,000

75,000

FDM 225

2,250,000

112,500

FDM 300

3,000,000

150,000

FDM 350

3,500,000

175,000

FDM 500

5,000,000

Contact ATI of New York for the Power Flame Type FDM

As the authorized representative for Power Flame, ATI of New York offers their entire state-of-the-art lineup of equipment. Our experienced team will carefully listen to your facility's needs and guide you to the most suitable solution. Whether you have specific questions about the Power Flame FDM or any other model, we are here to help you make the most economical and efficient decision.

Contact ATI of New York today.
