What Are Fulton Blowdown Separators?

What Are Fulton Blowdown Separators?

Fulton Blowdown Separators

Fulton’s blowdown separators are designed to safely separate steam vapor from the blow-off water of your boiler. This critical piece of equipment transports water from your boiler during blowdown and safely reduces it to the proper atmospheric pressure for disposal.

As a leader in boiler equipment and technology, Fulton’s blowdown separators are engineered with the same quality and integrity you’ve come to expect from the manufacturer. ATI of New York is proud to be the authorized manufacturer’s representative for Fulton Boilers. We offer their entire line of up of cutting-edge equipment as well as decades of experience to guide you through the process.

Continue reading to learn more about Fulton blowdown separators and why they are regarded as the best in the industry.

Fulton Blowdown Separators

Fulton’s blowdown separators are engineered with the finest quality materials. All Fulton blowdown separators are created to exceed or meet ASME Code. This equipment includes certain special features to ensure safe boiler blow down.

Most importantly, Fulton’s blowdown separators are uniquely created to operate with the least possible amount of maintenance. A few key highlights of Fulton’s blowdown separators include:

  • Safe steam exit — All of Fulton’s blowdown  separators are designed to promote the safe expelling of steam through the vents.
  • Unique baffle plate design — The unique design of Fulton’s blowdown separators ensure pressure and steam flash is absorbed by the baffle plate.
  • Simple maintenance — Each Fulton blowdown separator includes a large 3”x4” handhole to promote quick and easy inspection and cleaning.
  • Effective design — Fulton’s blowdown separators allow sludge and water to pass through the drain into the sewer.
  • Simple installation — With a Fulton blowdown separator, you’ll enjoy fast and easy hook up to the boiler.
  • Engineered to code — Each Fulton blowdown separator is engineered and welded to ASME Pressure Vessel Code.
Fulton Blowdown Separators

Fulton’s Flexible and Versatile Blowdown Separators

Fulton’s blowdown separators are offered in the following models:

  • Model F10 is designed for boilers ranging from 4-10 HP with a capacity to hold up to 7.9 gallons.
  • Model F20 is designed for boilers ranging from 11-20 HP with a capacity to hold up to 17.4 gallons.
  • Model F30 is designed for boilers ranging from 21-30 HP with a capacity to hold up to 22 gallons.
  • Model F50 is designed for boilers ranging from 31-50 HP with a capacity to hold up to 35.6 gallons.
  • Model F75 is designed for boilers ranging from 51-75 HP with a capacity to hold up to 40.8 gallons.
  • Model F100 is designed for boilers ranging from 76 -100 HP with a capacity to hold up to 58.75 gallons.
  • Model F150 is designed for boilers ranging from 101-150 HP with a capacity to hold up to 70.5 gallons.

ATI of New York can help facilitate the creation of custom Fulton blowdown separators for larger horsepower applications. Simply reach out to us and we will work with Fulton to engineer custom units suitable for your application.

Contact ATI of New York

When it comes to meeting your boiler & combustion related equipment needs, ATI of New York is your one-stop solution. We bring decades of experience working with facility managers, owners, and more to engineer viable solutions. A few of the most common industries we serve include:

We are the authorized manufacturer’s representative for Fulton and offer their entire line of products, including:

  • Condensing and non-condensing commercial heating boilers
  • Fuel-fired vertical tubeless steam and hot water boilers
  • Electric steam and hot water boilers
  • Customized sequencing and complete system control systems.

Contact ATI of New York today for Fulton blowdown separators or other Fulton products.
